No further hurdles to DEE completion
FE
Published :
Oct 26, 2024 22:20
Updated :
Oct 26, 2024 22:20



The Dhaka Elevated Expressway (DEE) has had a troubled past as there had been numerous delays in completing every phase of the project. Needless to say, as it involved a steep learning curve for the government of the day and involved numerous issues ranging from land acquisition and operational problems amongst the multiple parties involved in the construction of this milestone project. Dhaka city has long been in need of an elevated expressway network as for more than a decade, traffic speeds have been crawling to single digit km per hour. Obviously, things needed to change as commerce boomed and the country needed fast track movement of cargo in and out of Dhaka city. It is with that vision in mind, DEE is being implemented.

The political turmoil notwithstanding, work on the final 25 per cent of the elevated expressway has been at a standstill since February, 2024 for reasons that are entirely legal in nature. The whole project is worth US$1.2 billion and the Thai company had been in conflict with the other two Chinese contractors that were implementing the project together. On October 20, the Singapore International Arbitration Centre (SIAC) discharged the status quo on share transfer of ITD authority to the Chinese firms and now it is hoped that work can resume without further delay. It is interesting to note that the contract had originally been awarded to Italian-Thailand Development Public Limited (ITD) way back in 2011 and now the year is 2024. This crucial project had been plodding on for more than a decade and the said company had, over the years, run short of funds and had been awarded several time extensions and cost overruns. It speaks volumes of the way infrastructure development was done in the past and things continued to get more and more complicated with the entry of two Chinese companies into the deal.

The question that comes to mind is where were Bangladeshi authorities in all this? Why weren't steps taken when things went awry in terms of getting requisite funds by contracted companies delaying project implementation that ultimately ended up costing years in delay and cost revisions upward? There appeared to be little or no compunction on the part of the concerned authorities of the previous government to expedite the process. Rather, as with most of the mega-infrastructure projects undertaken in the past decade and a half, the modus operandi had been to award contracts to foreign companies and hope for the best. That is not how development is achieved, rather that is the perfect recipe for corruption to take place - at the cost of wastage of public money and years lost in implementation. As the High Court in Bangladesh finally cleared the case on September 01, 2024, the parties concerned went for international arbitration in Singapore and a verdict had been delivered in less than two months. The fault lies with the Bangladesh Bridges Authority (BBA) in its failure to take active measures against contractors who wasted precious time and resources to complete the project.

This experience should act as a case study for future development work undertaken by the current government to avoid the pitfalls in contracts management, and penalties and exit policies need to be carefully defined in public-private partnership contracts to avoid situations like this. Every single mega-project needs to be reviewed to find out what can be done to rectify signed contracts so that the country does not suffer undue headache because of a lack of professionalism on our part.​


Padma Bridge wins International Bridge Association's "Contribution to International Social Development" Award​


Date: November 22, 2024 【Font size: large, medium, small】
Print
​

  Zurich, Switzerland: At 18:00 local time on November 12, the 2024 Awards Ceremony of the International Association for Bridge and Structural Engineering (IABSE) was held in Zurich, Switzerland.

The Padma Bridge in Bangladesh, which was surveyed and designed by China Railway Major Bridge Engineering Group Co., Ltd., constructed by China Railway Major Bridge Engineering Group Co., Ltd., and built by China Railway Shanqiao and China Railway Jiuqiao under China Railway Industry, won the "International Social Development Contribution" Award.

The Padma Bridge was completed and opened to traffic on June 25, 2022.

It is currently the largest bridge construction project in Bangladesh and the first steel truss bridge with a fully welded structure, ultra-thick plate, and dual-use road and rail using European standards.

The bridge spans the Padma River in Bangladesh. The main bridge is 6.15 kilometers long. The upper level is a two-way four-lane highway, and the lower level is a single-track railway.

After the completion and opening to traffic, the bridge ended the history of ferrying passengers and freight across the Padma River between the 21 southern districts of Bangladesh and the capital Dhaka, eastern and northern Bangladesh, and shortened the crossing time from more than 7 hours by ferry or detour to 10 minutes, benefiting nearly 80 million people in Bangladesh, improving regional connectivity, and promoting the economic development of Bangladesh and even South Asia.
​
Project Description:
The main bridge of Padma Multipurpose Bridge has a length of 6150 meters, featuring an outstanding design with large-diameter steel raking pile composite foundation and epoxy-glued roadway deck - continuous steel truss composite structure. Its successful construction has increased national GDP and reduced poverty rate.

Judges Comments
With an overall length of over 6km, this long-awaited crossing provides an essential transportation and services link between the two previously disconnected parts of Bangladesh, separated by the huge Padma River. The double level steel truss with composite concrete deck slabs, carries rail on the lower level and a 4-lane highway on top. Very deep riverbend silt with excessive scour depths and the risk of liquefaction demanded an innovative approach for the large diameter raking steel piles with lengths up to 125m.

Structural Designer
AECOM

Location
Dhaka, Bangladesh




More images of Padma Bridge during construction below

Last edited:



Custom made piling hammer Made in Germany by Menck (largest ever made globally) since piles were driven deep into riverbed. MENCK's MHU 3500S hydraulic hammer, known as the "Gentle Giant," was used to drive the longest piles in the world for the Padma Bridge project in Bangladesh, reaching depths of up to 122 meters. This hammer is part of MENCK's extensive experience in providing specialized pile driving solutions for major construction projects. More here - https://rulethesite.com/the-challenges-the-story-of-padma-bridge/

Padma Bridge boasts a number of pioneering epochal record-breaking firsts
  1. Steel piles were driven at a depth of 122 meters for the pillars of the Bridge. Piles have a radius of three meters. Number of piles are 7 to 9 per pillar.
  2. Earthquake bearing wise - the capacity of ‘Fractional Pendulum Bearings’ used is 10,000 tons which is highest capacity globally. Padma Bridge can withstand a magnitude 9 earthquake.
  3. A $1.10 billion contract was awarded to Chinese contractor Sinohydro Corporation for river training. This was necessary to tame river flow and resulting erosion on the banks.
  4. Special chemicals and micro fine cement were used in piling fillers. These were specified by the bridge designer (AECOM - USA) for strength of piling and were sourced from Australia.
  5. Menck piling hammer was used which was the world's largest hammer at the time. This several hundred ton item was supplied by air from Menck's HQ in Germany by air (using an AN-225 airplane, I saw the video), transferred to a special 24 axle logistics carrier at Dhaka airport and sent to Padma Bridge site via road.
